Shelly Pro Dimmer 0/1-10V PM
SKU: BRT-565832$ 95.29
- Description Specifications A smart dimmer that allows you to control and adjust lighting to suit your needs. With Wi-Fi and LAN connectivity, as well as energy consumption monitoring, it is the perfect solution for precise and energy-efficient home lighting control. The device supports various light sources, including dimmable LEDs and halogen lamps.Features:Supports dimmable LEDs, halogen lamps, and incandescent bulbs.Real-time energy consumption monitoring.Connectivity: LAN and Wi-Fi for a stable connection.Compatibility with Google Assistant and Amazon Alexa.Protection against overload and overheating.Operating voltage: 110–230V AC, 50/60 Hz.Built-in timers for automated control.Compact design: Fits into standard electrical panels.Applications:Ideal for adjusting lighting in living spaces, offices, and commercial areas. Perfect for creating comfort and a stylish ambiance. Size (HxWxD): 94x19x69 mm Weight: 75 g Screw terminals max torque: 0.4 Nm Conductor cross section: 0.5 to 2.5 mm² / 20 to 14 AWG (green connectors) 0.5 to 1.5 mm² / 20 to 16 AWG (blue connector) Conductor stripped length: 6 to 7 mm (green connectors) 5 to 6 mm (blue connector) Mounting: DIN rail Ambient working temperature: -20 °C to 40 °C Humidity: 30 % to 70 % RH Max. altitude: 2000 m Power supply: 110 - 240 V~ 50/60 Hz Power consumption: External protection: 10 A, tripping characteristic B or C 6 kA interrupting rating Energy limiting class 3 Dimming type: Trailing edge Max. output power: 200 W Voltmeter (AC): Yes Ammeter (AC): Yes Power and energy meters: Yes Internal-temperature sensor: Yes Radio: Wi-Fi: Protocol: 802.11 b/g/n RF band: 2401 - 2483 MHz Max. RF power: Range: Up to 30 m indoors and 50 m outdoors (Depends on local conditions) Bluetooth: Protocol: 4.2 RF band: 2400 - 2483.5 MHz Max. RF power: Range: Up to 10 m indoors and 30 m outdoors (Depends on local conditions)
