2-port HDMI switch 1-output 8K@60FPS grey
SKU: BRT-565832$ 99.32
- Description Specifications Files 1 This high-performance HDMI switch allows you to connect up to two HDMI source devices to a single display simultaneously. Supporting cutting-edge 8K resolution at 60 Hz, it provides exceptional clarity and fluid motion for the most demanding home cinema and gaming setups.The device features a convenient manual switch button, making it easy to toggle between input signals without cable swapping. Integrated LED status indicators provide immediate visual feedback on which source is currently active. Its compact and modern grey design ensures it fits discreetly into any multimedia arrangement, while the USB-C power port guarantees reliable performance for high-bandwidth data transmissions.Note!: The HDMI switcher does not work as a splitter! Item number: 77791Connectors - Inputs: 2x HDMI™ socket (Type A)Connectors - Outputs: HDMI™ socket (Type A)Input: 5.0 V, 0.5 A, 2.5 WData transmission rate: max. 48.0 Gbit/sMax. resolution: 8K @ 60 Hz (7680x4320), Full HDSupported audio standards: Dolby Atmos, Dolby Digital HD (DTS HD), Dolby Digital True HD, Dolby Digital 5.1 (AC-3), Dolby 5.1, Dolby 7.1., LPCM, Stereo, Enhanced Audio Return Channel (eARC), Audio Return Channel (ARC)Protection class: IIIOperating Temperature: 0 °C ~ 40 °CDimensions: 46 x 42.9 x 15 mmWeight: 30 gExternal power supply (Not in scope of delivery): USB-C™ plug, min. 5.0 V, 0.5 A, 2.5 WIn the box:HDMI™ Switch Box 2 to 1 (8K @ 60 Hz)User manual 77791-GBY Manual EN387.11KBDownload
